Automatic Pharma Blister Packing Machine Operating Procedures A?

Mar. 27, 2019

1. The Automatic Pharma Blister Packing Machine turns on the green indicator light, and the two heating switches are formed to open and operate respectively. The temperature controller controls the forming temperature, and the preset temperature is preset to 100oC. The second temperature controller controls the heat sealing, and the temperature preset is 130oC-140oC. The upper and lower molding and heat sealing temperature controller preset temperature, depending on the details.

2. Put down the pressing block on the feeding roller, the temperature of the forming heating plate is in place, and then open the main machine. The plastic PVC is first formed, and the forming blister is matched with the hole of the heat sealing die. Pay attention to the heat sealing die cylinder and put down the heat sealing die to press the aluminum foil. Aluminum foil will drive to the cut. Look at the plastic (refer to the machine surface has been formed PVC) walking can be left and right offset. If there is a tendency, the direction of the pressure roller should be adjusted.

3. If the aluminum foil of the Automatic Liquid Sachet Packing Machine is tilted left and right, the adjustable roller seat can be adjusted. If the front and rear are biased toward the adjustable box.

4. After the heat seal is normal, turn the feeder switch and the gate properly, so that the medicine (tablet capsule, grain clothing) enters the feeding room in an appropriate amount. If there is a small amount of cylinder material, it can be manually filled. If any drug is brought in, When the mold is heat-sealed, the synchronization will be seriously affected. Therefore, when the aluminum foil is sealed, it is stuck on the mold and should be shut down for disposal.
